Field Cbr Test Set
|
||||
Test Ini Dimaksudkan Untuk Memeriksa Nilai Cbr Langsung Ditempat Atau Dilokasi Pemadatan
RS-260, FIELD CBR TEST SET
ASTM D-4429
For determining CBR value on place.
RS-261 Mechanical Jack
" Cast alumunium housing, 5 tons cap,
hand operated, 2 speeds. "
Consist of :
RS-261.1 Mechanical Jack 1 Pc
5 tons capacity
RS-261.2 Swivel Hand 1 Pc
Cast alumunium
RS-262 Field Penetration Piston
Machined steel, galvanized, adjustable height
Consist of :
RS-262.1 Penetration Piston 1 Pc
Machined steel, galvanized, 1.954 " piston dia.
RS-262.1 Extension Set 1 Set
" Machined steel, galvanized, 5 cm, 10 cm, 20 cm
and 60 cm, provided with connecting adaptor "
RS-263 Reference Beam 1 Set
Steel pipe, 160 cm span
RS-264 Circular Surchange Weight 1 Pc
Machined steel, galvanized, 10 " dia., 10 lbs weight
RS-265 Slotted Surchange Weight 1 Pc
Machined steel, galvanized, 8 " dia., 10 lbs weight
RS-266 Slotted Surchange Weight 1 Pc
Machined steel, galvanized, 8.5 " dia., 20 lbs weight
RG-101.5 Proving Ring 1 Set
2.000 lbs capacity
RG-101.7 Proving Ring 1 Set
10.000 lbs capacity
RG-137 Dial Indicator 1 Pc
Range 30 x 0.001 mm
RG-140 Dial Holder 1 Pc
Magnetic
Dimension ( l x w x h) : 140 x 35 x 35 cm
